DELABIE F5ST2037

F5S-Therm self-closing thermostat mixer DN 15 as a finishing set for wall installation in the basic roughing-in set, for showers. Hydraulically controlled, for connection to hot and cold water. Functional block with integrated self-closing FRAMIC cartridge, thermostat and pre-assembled hygiene unit including sensor with control electronics and 6 V lithium battery (CR-P2) for automatic hygienic flushing, program-controlled thermal disinfection (additional bypass cartridge with solenoid valve required) and storage of statistical data. Additional provision for a second bypass cartridge with solenoid valve for separate flushing of the cold water line and for separate sampling of cold or hot water. Self-closing FRAMIC cartridge, low-maintenance and stagnation-free, with ceramic disc technology, self-closing, independent of flow pressure due to separate chamber design. Flow time continuously adjustable. Thermostat with metal handle with adjustable and anti-twist protected temperature stop and possibility for manual thermal disinfection. Completely made of metal, visible parts polished and chrome-plated. Mounting frame including profile seal, stainless steel cover plate 190 x 245 mm with concealed screw fastening, chrome-plated plastic rosettes, backflow restrictors and strainers. Depth adjustment 25 mm.
