SKU: 8146777930
Delivery time: 21 days
Color: Chrome High-gloss chrome
Couldn't load pickup availability
Returns
Returns
Shipping countries
Shipping countries
At CitroenAir, we ship worldwide. However, not all countries are set as standard shipping countries. Please check here if your country is on the list of shipping countries.
Is your country not listed? No problem, simply request a quote. We will prepare a suitable quote for you as soon as possible, so you can still order from us.
Private individual
Private individual
We do not supply to private individuals. Orders from private individuals will be cancelled.
CitroenAir supplies exclusively to business customers such as healthcare organisations, companies, architects and installers.
Questions
Questions
Questions about this product or in need of advice? Use the chat function bottom left, contact us via info@citroenair.eu or call us on weekdays between 08:30 and 17:00 at +31 (0)318 59 29 30.
Concealed urinal flush valve with timed flow.
For standard urinals or urinals with siphon action.
For flush-mounted installation.
Installation depth can be adjusted from 20 to 35 mm.
Stainless steel wall plate Ø 130 mm.
Flush duration ~3 seconds.
Flow rate preset to 0.15 l/sec at 3 bar, adjustable.
Solid brass housing M½".
30-year warranty.
This model does not have a waterproof installation box. The installer must ensure that the installation area is watertight and that any leaks or condensation can drain away (see installation manual).
Specifications
| Article number | 8146777930 |
|---|---|
| Brand | Delabie |
| Weight | 0.65 kg |
| Operation | Self-closing |
| Colour | Chrome |
| Material | Brass |
| Assembly | Recessed |
| Finish | High-gloss chrome |
