CONPRIMUS stainless steel shower panel APP Thermostat-E, E-control, mains operation, KWH flush, cleaning stop, hygiene flush, piezo button, mains operation, thermostat, DN15.
Shower panel with electronically controlled mixing device, including scald protection, for wall mounting. For use in new builds and renovations in commercial, semi-public, and public sanitary facilities.
Operating voltage (mains operation, multiple installation): 24 V/DC
Operating pressure: 2.0-5.0 bar
Water temperature (max.): 70 °C (briefly for TD 80 °C)
Water temperature for thermal disinfection: briefly 80 °C for thermal disinfection
Flow rate DN15: 0.15 l/s (flow regulator)
Flow rate for thermal disinfection DN15: 0.05 l/s - adjustable via Service APP and CNX, please note the maximum water temperature). Memory temperature setting: after the shower time ends (or is stopped by pressing the piezo button again), the set temperature is saved for 30 seconds
Water flow time adjustment range: 3 – 180 s
Factory setting water flow time: 30 s
Hygiene flush adjustment range: factory setting: deactivated, 24, 48 or 72 hours, adjustable via piezo button, CNX or Service APP
Preset temperatures: Stand-by temperature when the piezo button is pressed 38 °C (can be set from 100 % cold to max. 43 °C (temperature range) via E-Control rotary knob. If the cold water supply fails, the water supply is stopped when 48 °C is reached (factory setting
Memory temperature setting: After the shower time ends (or is stopped by pressing the piezo button again), the set temperature is saved for 30 s
Electronic protection class: IP68
Dimensions (WxHxD): 220x1400x40 mm
Required accessories:
CONO513000 - Power supply 24V/DC 4.2 A installation box (Power supply 24V/DC 4.2 A installation box)
CONO030010 - CONHEAD rain shower head SHORTY, for shower elements, chrome-plated brass, DN15 (CONHEAD SHORTY shower panel chrome)
Specifications
| Article number | 862CONE1111219580 |
|---|---|
| Brand | CONTI+ |
| Weight | 13.0 kg |
| Operation | Piezo push-button |
| Colour | Stainless steel |
| Material | Stainless steel |
| Assembly | Surface mounted |
| Power suply | Netvoeding |
| Collection | CONTI+ Conprimus |
| Finish | Brushed |
